| Model Number |
CP510-KGNN-S00, CP510-KGNN-S01 |
|
|
|
| Materials |
Steel, Plastic, Tempered Glass |
|
| Dimensions (L x W x H) |
445 x 204 x 463mm (incl. Protrusions), 436 x 204 x 448mm (excl. Protrusions) |
|
| Volume |
39.85L (exlc. Protrusions) |
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX |
|
|
|
| 2.5″ / 3.5″ Drive Bays (Combo) |
2 |
|
|
|
| I/O Panel |
1x USB 3.2 Gen 1 Type-A, 1x USB 2.0, 1x 3.5mm Headset Jack (Audio+Mic), 1x ARGB Controller |
|
| Pre-installed Fans – Front |
3 x 120mm ARGB Fan (CP510-KGNN-S00) |
|
| Pre-installed Fans – Rear |
N/A |
|
| Fan Support – Top |
2x 120mm, 2x 140mm |
|
| Fan Support – Front |
3x 120mm, 2x 140mm |
|
| Fan Support – Rear |
1x 120mm |
|
| Radiator Support – Top |
120 / 240mm (Memory bar height limit 35mm, First assemble the memory and then assemble the Radiator) |
|
| Radiator Support – Front |
120mm, 140mm, 240mm, 280mm |
|
| Radiator Support – Rear |
120mm |
|
| Clearance – CPU Cooler |
161mm |
|
|
|
| Clearance – GFX |
350mm (w/o front fans & radiator) |
|
|
|
|
|
| Power Supply Support |
Bottom Mount, ATX |
|
|
|
|
|
|
https://www.coolermaster.com/catalog/cases/mid-tower/cmp-510/#overview
| Product Name |
MWE Bronze 650 |
|
|
|
| ATX Version |
ATX 12V V2.31 |
|
|
|
| Operation Voltage |
100-240Vac |
|
|
|
|
|
|
|
| Dimensions (L x W x H) |
140 x 150 x 86 mm |
|
|
|
|
|
| Power Good Signal |
100 – 500 ms |
|
| Hold Up Time |
16ms at 80% Load |
|
| Efficiency |
85% @ Typical Load |
|
|
|
|
|
| Operating Temperature |
0-40°C |
|
| Protections |
OPP, OVP, UVP, OCP, OTP, SCP |
|
| Regulatory |
TUV-RH, CE, CCC, KC, EAC, RCM, cTUVus, FCC, BSMI |
|
|
|
| CPU 12V 4+4 Pin Connectors |
1 |
|
|
|
| Peripheral 4 Pin Connectors |
4 |
|
| FDD Cable 4 Pin Connectors |
1 |
|
| PCI-e 6+2 Pin Connectors |
4 |
|
|
|
|
|
|
|
|
|
