SEASONIC 550W S21 III 80 PLUS BRONZE NON

S12III SERIES

The S12III Bronze Series is available in the standard ATX Form Factor and in wattages that are most common for a PC system. The Seasonic S12III-Series achieves 80 PLUS® Bronze standard of providing at least 82 %, 85 % and 82 % power usage efficiency at 20 %, 50 % and 100 % operating loads, respectively. This efficiency, combined with Active Power Factor Correction, enables the S12III Bronze series power supplies to lessen energy waste, which translates into savings on the costs of energy costs for its users. In addition to being greatly efficient, the S12III units utilize the LLC resonant converter design, and the industry’s leading Smart and Silent Fan Control (S2FC).

For customers in the EU, the scheduled launch of the S12III series is Q3 2019*. For more information about product availability, please contact your local Seasonic representative.

* Subject to change without prior notice.

  • ATX 12 V
  • Fixed cables
  • 80 PLUS Bronze Certified
  • Dimensions: 140 mm (L) x 150 mm (W) x 86 mm (H)
EGP 1,200.00

Out of stock


Description

SPECIFICATIONS

SSR-550GB3

Technical Specifications
80PLUS® Bronze
Form Factor Intel ATX 12 V
Dimensions 140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control Seasonic S2FC
Fan Bearing Sleeve bearing
Life Expectancy 30,000 hours at 40 °C, 15 % – 65 % RH
Cable Information Modularity Fixed cable
Cable type Flat black cables
Electrical Features Operating Temperature 40 °C
MTBF @ 25 °C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, Gost-R, UkrTEST, CB , BSMI, Semko, CCC, CE, FCC, C-tick
Environmental Compliance Energy Star, RoHS, WEEE, REACH
Warranty 5 Years
Power Output
AC Input Voltage: 110 V – 240 V
Current: 8 A – 4 A
Frequency: 50 Hz – 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 20 A 20 A 45.5 A 0.3 A 2.5 A
100 W 546 W 3.6 W 12.5 W
Total continuous power 550 W

https://seasonic.com/s12iii

Additional information

POWER CERTIFICATION

80+ BRONZE

POWER MODULAR

FIXED CABLES

POWER WATTAGE

500W-550W
