The newly upgraded FOCUS GM series is the successor to the FOCUS Series, which became an instant the top seller in the power supply market after its launch in 2017. Besides the small change in the series naming, the PSU housing and its packaging are also updated to be in line with the concept of the OneSeasonic Initiative.
The exact time to market depends on your location. Please contact your local Seasonic Representative to obtain more information.
Out of stock
Technical Specifications | ||
---|---|---|
80PLUS® | Gold | |
Form Factor | Intel ATX 12 V | |
Dimensions | 140 mm (L) x 150 mm (W) x 86 mm (H) | |
Fan Information | Fan Size | 120 mm |
Fan Control | S2FC | |
Fan Bearing | Fluid Dynamic Bearing | |
Life Expectancy | 50,000 hours at 40 °C, 15 % – 65 % RH | |
Cable Information | Modularity | Semi-modular |
Cable type | Webbed cables (attached) Flat black cables(modular) |
|
Electrical Features | Operating Temperature | 0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
MTBF @ 25 °C, excl. fan | 100,000 hours | |
AC Input | Full Range | |
Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
Warranty | 7 Years |
Power Output | ||||||
---|---|---|---|---|---|---|
AC Input | Voltage: 100 V – 240 V | |||||
Current: 10 – 5 A | ||||||
Frequency: 50 Hz – 60 Hz | ||||||
DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
Maximum Power | 20 A | 20 A | 62 A | 0.3 A | 3 A | |
100 W | 744 W | 3.6 W | 15 W | |||
Total continuous power | 750 W |
POWER CERTIFICATION | 80+ GOLD |
---|---|
POWER MODULAR | SEMI MODULAR |
POWER WATTAGE | 700W-750W |
