Seasonic has included a PSU tester in the box that will let consumers perform a quick and easy jump start on the power supply. Each PRIME Ultra Series power supply will also ship with a SATA 3.3 adapter to support the “Power Disable” (PWDIS) feature of the newer, high-capacity hard drives. The inline capacitors on the cables were removed, which takes away the bulkiness inside the system. To maximize flexibility, the 180-degree SATA connectors ensuring more flexibility and easier installation.
Out of stock
Technical Specifications | ||
---|---|---|
80PLUS® | Gold | |
Cybenetics Efficiency Level | TBA | |
Cybenetics Noise Level | TBA | |
Form Factor | Intel ATX 12 V | |
Dimensions | 170 mm (L) x 150 mm (W) x 86 mm (H) | |
Fan Information | Fan Size | 135 mm |
Fan Control | Premium Hybrid Fan Control | |
Fan Bearing | Fluid Dynamic Bearing | |
Life Expectancy | 50,000 hours at 40 °C, 15 % – 65 % RH | |
Cable Information | Modularity | Fully Modular |
Cable type | Flat black cables | |
Electrical Features | Operating Temperature | 0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
MTBF @ 25 °C, excl. fan | 150,000 hours | |
AC Input | Full Range | |
Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
Power Output | ||||||
---|---|---|---|---|---|---|
AC Input | Voltage: 100 V – 240 V | |||||
Current: 11 – 5.5 A | ||||||
Frequency: 50 Hz – 60 Hz | ||||||
DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
Maximum Power | 20 A | 20 A | 70 A | 0.3 A | 2.5 A | |
100 W | 840 W | 3.6 W | 12.5 W | |||
Total continuous power | 850 W |
Cable type | Connector(s) per cable | Total Length (mm) | Number(s) of cable(s) included |
---|---|---|---|
MB (24/20 pins) | 1 | 610 | 1 |
CPU (8/4 pins) | 1 | 650 | 2 |
PCIe (8/6 pins) | 2 | 750 | 3 |
PCIe (8/6 pins) | 1 | 750 | 0 |
SATA | 4 | 810 | 0 |
SATA | 4 | 800 | 1 |
SATA | 4 | 760 | 1 |
SATA | 2 | 700 | 0 |
SATA | 2 | 570 | 0 |
SATA | 2 | 470 | 0 |
SATA | 2 | 450 | 1 |
Molex | 3 | 690 | 1 |
Molex | 2 | 470 | 1 |
Molex to SATA 3.3 Adapter | 2 | 300 | 1 |
Molex to FDD Adapter | 1 | 101 | 1 |
POWER CERTIFICATION | 80+ GOLD |
---|---|
POWER MODULAR | FULL MODULAR |
POWER WATTAGE | 850W |
