Specifications
EAN Code
4719512046531
UPC Code
884102025518
Package Information
383 x 252 x 140 mm /
15.1 x 9.9 x 5.5 inches
Carton Dimensions
577 x 393 x 279 mm /
22.7 x 15.5 x 11 inches
Unit / Carton
4 pcs
Carton / Pallet
15 pcs
AC INPUT
100-240V~ 15-7.5A 60-50Hz
DC OUTPUT
+3.3V
+5V
+12V
-12V
+5Vsb
25A
25A
100A
0.5A
3A
OUTPUT
125W
1200W
6W
15W
POWER
1200W
Packaging Information
Model Number
RSC00-AFBAG1-XX
Type
Intel Form Factor ATX 12V V2.31
Dimensions
150 x 190 x 86mm / 5.9 x 7.5 x 3.4 inch
Input Voltage
100-240Vac (Full Range)
Input Current
15 – 7.5A
Input Frequency Range
60 – 50Hz
PFC
Active PFC (>0.9)
Power Good Signal
100-500ms
Hold Up Time
>17ms
Efficiency
93% Typical
MTBF
>100,000 Hours
Protection
OVP / UVP / OPP / OTP / OCP / SCP
Output Capacity
1200W
Operation Temperature
0-40℃
Regulatory
CE/TUV/TUV-SUDNRTL/FCC/EAC/CCC/BSMI/RCM/KC
Fan
Silent FDB 135mm
Connectors
M/B 20+4 Pin x 1
CPU 4+4 Pin x 2
PCI-e 6+2 Pin x 12
SATA x 12
4 Pin Peripheral x 9
4 Pin Floppy x 1
