| MODEL |
| MPE-8501-AFAAG |
| ATX VERSION |
| ATX 12V |
| PFC |
| Active PFC |
| INPUT VOLTAGE |
| 90-264V |
| INPUT CURRENT |
| 12-6A |
| INPUT FREQUENCY |
| 47-63Hz |
| DIMENSIONS (L X W X H) |
| 160 x 150 x 86 mm |
| FAN SIZE |
| 120mm |
| FAN BEARING |
| HDB |
| FAN SPEED |
| 1500 RPM |
| NOISE LEVEL @ 20% |
| 0 dBA |
| NOISE LEVEL @ 50% |
| 17.8 dBA |
| NOISE LEVEL @ 100% |
| 25.9 dBA |
| EFFICIENCY |
| 90% @ Typical Load |
| 80 PLUS RATING |
| 80 PLUS Gold |
| ERP 2014 LOT 3 |
| Yes |
| OPERATING TEMPERATURE |
| 0-50°C |
| POWER GOOD SIGNAL |
| 100 – 150 ms |
| HOLD UP TIME |
| >16ms at 100% Load |
| MTBF |
| >100,000 Hours |
| PROTECTIONS |
| OVP, OPP, OTP, SCP, OCP, UVP |
| REGULATORY |
| TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI |
| ATX 24-PIN CONNECTORS |
| 1 |
| EPS 4+4 PIN CONNECTORS |
| 1 |
| EPS 8 PIN CONNECTOR |
| 1 |
| SATA CONNECTORS |
| 12 |
| PERIPHERAL 4-PIN CONNECTORS |
| 4 |
| PCI-E 6+2 PIN CONNECTORS |
| 4 |
