| Special Technology | None |
|---|---|
| Protections | OVP (Over Voltage) | UVP (Under Voltage) | SCP (Short Circuit) | OTP (Over Temp) | OPP (Over Power) |
| PSU Compatibility | ATX12V v2.31 and EPS12V 2.91 standards |
| ATX Connector | 1 |
| ATX12V Version | v2.31 |
| Cable Type | Sleeved and Flat Black Cables |
| Continuous Power W | 650 Watts |
| EPS Connector | 1 |
| Fan Bearing Technology | Sleeve Bearing |
| Fan Size MM | 140mm |
| MTBF Hours | 100,000 hours |
| Multi GPU Ready | No |
| SATA Connector | 7 |
|---|---|
| Modern Standby | No |
| Dimensions | 150mm x 86mm x 125mm |
| Modular | No |
| Floppy Connector | 1 |
| PCIe Connector | 2 |
| PSU Form Factor | ATX |
| Zero RPM Mode | No |
| Single Multiple 12V Rail Toggl | No |
| 80 PLUS Efficiency | Bronze |
| Weight | 2.32 |
CV650 DC CABLE LISTING
| QTY | Cable | Connectors per cable |
Total connectors |
Connector Spacing |
Total length |
|---|---|---|---|---|---|
| 1 | ATX Cable 24 pin
|
1 | 1 | – | 550mm (± 10mm) |
| 1 | EPS/ATX12V 8 pin (4+4) cable
|
1 | 1 | – | 600mm (± 10mm) |
| 1 | PCIe 8 pin (6+2) cable
|
2 | 2 | 550mm, 120mm | 670mm (± 10mm) |
| 2 | SATA Cable (3 SATA)
|
3 | 6 | 450mm, 120mm, 120mm | 690mm (± 10mm) |
| 1 | SATA-PATA-PATA-FDD
|
4 | 4 | 450mm, 120mm, 120mm, 120mm | 810mm (± 10mm) |
