Technical Specifications
-
Picture/Display
- Panel Size
-
23.8 inch/60.5 cm
- Aspect ratio
-
16:9
- LCD panel type
-
VA LCD
- Backlight type
-
W-LED system
- Pixel pitch
-
0.2745 x 0.2745 mm
- Brightness
-
300 cd/m²
- Display colours
-
16.7 M
- Color gamut (typical)
-
NTSC 113%*, sRGB 126%*, Adobe RGB 110%*
- Contrast ratio (typical)
-
1000:1
- SmartContrast
-
Mega Infinity DCR
- Response time (typical)
-
1 ms (Grey to Grey)*
- Viewing angle
-
-
178º (H)/178º (V)
-
@ C/R > 10
-
- Picture enhancement
-
SmartImage game
- Maximum resolution
-
1920 x 1080 @ 180 Hz*
- Effective viewing area
-
527.04 (H) x 296.46 (V)
- Scanning Frequency
-
30–200 kHz (H)/48–180 Hz (V)
- sRGB
-
Yes
- Flicker-free
-
Yes
- Pixel Density
-
93 PPI
- LowBlue Mode
-
Yes
- Display Screen Coating
-
Anti-Glare, 3H, Haze 25%
- EasyRead
-
Yes
- HDR
-
HDR 10 supported
- Smart Crosshair
-
Yes
- Smart MBR
-
0.5 ms*
-
Connectivity
- Signal Input
-
HDMI 2.0 x 2, DisplayPort 1.4 x 1
- Sync Input
-
Separate Sync
- Audio (In/Out)
-
Audio out
- HDCP
-
HDCP 1.4 (HDMI/DP), HDCP 2.2 (HDMI/DP)
-
Convenience
- Built-in Speakers
-
2 W x 2
- Plug & Play Compatibility
-
-
DDC/CI
-
Mac OS X
-
sRGB
-
Windows 11/10
-
- User convenience
-
-
Power On/Off
-
Menu/OK
-
Input/Up
-
Game Settings/Down
-
SmartImage game/Back
-
- OSD Languages
-
-
Brazil Portuguese
-
Czech
-
Dutch
-
English
-
Finnish
-
French
-
German
-
Greek
-
Hungarian
-
Italian
-
Japanese
-
Korean
-
Polish
-
Portuguese
-
Russian
-
Spanish
-
Simplified Chinese
-
Swedish
-
Turkish
-
Traditional Chinese
-
Ukrainian
-
- Other convenience
-
-
Kensington lock
-
VESA mount (100 x 100 mm)
-
-
Stand
- Height adjustment
-
130 mm
- Pivot
-
-/+ 90 degree
- Swivel
-
-/+ 30 degree
- Tilt
-
-5/20 degree
-
Power
- Power supply
-
-
Internal
-
100–240 VAC, 50–60 Hz
-
- Off mode
-
0.3 W (typ.)
- On mode
-
18.7 W (typ.)
- Standby mode
-
0.5 W (typ.)
- Power LED indicator
-
-
Operation – White
-
Standby mode – White (flashing)
-
- Energy Label Class
-
E
-
Dimensions
- Packaging in mm (WxHxD)
-
730 x 420 x 188 mm
- Product without stand (mm)
-
540 x 325 x 55 mm
- Product with stand(max height)
-
540 x 515 x 261 mm
-
Weight
- Product with packaging (kg)
-
7.38 kg
- Product with stand (kg)
-
4.56 kg
- Product without stand (kg)
-
2.76 kg
-
Operating conditions
- Altitude
-
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
- Temperature range (operation)
-
0°C to 40 °C
- MTBF
-
50 000 (Excluded backlight) hour(s)
- Relative humidity
-
20%-80 %
- Temperature range (storage)
-
-20°C to 60 °C
-
Sustainability
- Environmental and energy
-
RoHS
- Recyclable packaging material
-
100 %
- Specific Substances
-
-
Mercury free
-
PVC/BFR free housing
-
- Post-consumer recycled plastics
-
85%*
-
Compliance and standards
- Regulatory Approvals
-
-
CB
-
TUV/ISO9241-307
-
TUV-BAUART
-
EAC
-
BSMI
-
CE Mark
-
UKCA
-
EMF
-
FCC
-
ICES-003
-
-
Cabinet
- Colour
-
Charcoal
- Finish
-
Textured
-
What’s in the box?
- Cables
-
HDMI cable, DisplayPort cable, Power cable
- Monitor with stand
-
Yes
- User Documentation
-
Yes
