SPECIFICATIONS
Model
ATHENA M3
CASE
Case TypeMID Tower
MB SupportE-ATX、ATX、Micro-ATX、Mini-ITX
Synchronization5V 3-Pin Addressable Header
CASE ColorBlack
Expansion Slots7
MaterialSPCC & ABS & Tempered glass
WindowLeft
Radiator SupportTop: 360mm / Front: 360mm / Rear: 120mm
Fan SupportTop: 3 x 120mm , 2 x 140mm
Front : 3 x 120 mm
Rear: 1 x 120mm
Front : 3 x 120 mm
Rear: 1 x 120mm
Pre-installed FansFront: 3x 120mm ARGB PWM Fans
Rear: 1 x 120mm ARGB PWM Fan
Rear: 1 x 120mm ARGB PWM Fan
Drive Bays2 x 3.5″ or 1 x 2.5″+1 x 3.5″(HDD Cage)
4 x 2.5″
4 x 2.5″
I/O PortUSB 3.0 x1, Type Cx1, HD Audio x1, LED Control x1
ClearanceCPU cooler height limitation: 170mm
VGA length limitation: 420mm
VGA width limitation: 150mm
PSU length limitation: 200mm
VGA length limitation: 420mm
VGA width limitation: 150mm
PSU length limitation: 200mm
Dimension (L x W x H)460 x 218 x 450 mm
Net Weight6.59 kg / 14.53 lb
Pre-installed Control BOX8 Ports Hub (4 ports are used)
