SPECIFICATIONS
Product Name
EPIX II
Product Dimensions
125x98x154mm (LxWxH)
Heat Sink Dimensions
120x90x148mm (LxWxH)
Heat Sink Material
4pcs Heat Pipes/Aluminum Fins
Heat Pipe Dimensions
Ø6mm
TDP
225W
Top Cover
Infinity Mirror Plastic Top Cover Slow Motion Random RGB
CPU Support
Intel® LGA 1851/1700/1200/115X/20XX/1366
AMD® AM5/AM4
Fan Dimensions
120x120x25mm
Fan Speed
600-1600 ±10% RPM
Fan Bearing
Long Life Hydraulic Bearing
Fan LED Color
Slow Motion Random RGB
Fan Air Flow
69.3 CFM
Fan Air Pressure
2.9 mm-H2O
Fan MTTF
40,000 hours
Fan Noise Level
≤ 28.6 dBA
Fan Connector
4P PWM
Fan Rated Voltage
12 VDC
Fan Rated Current
≤ 0.23 A
Fan Power Consumption
≤ 3 W
