TypeATX12V v2.2
EfficiencyMeet 80 PLUS Bronze efficiency
Power Factor CorrectionAPFC with PF value of 0.99
Support MB Sync5V 3-pin Addressable (Digital) RGB Header Only
Dimension (L x W x H)140 x 150 x 86 mm
Support C6/C7 power stateNo
AC Input100-240V / 6-12A / 47-63Hz
DC Output+3.3V / +5V / +12V / -12V / +5Vsb
Max. Output Current20A / 20A / 60A / 0.3A / 2.5A
Max. Output Power130W / 720W / 3.6W / 12.5W
Total Power750W
ProtectionOVP / UVP / OPP / SCP / SP
Main Power1 (20+4 Pin)
CPU2 (4+4 Pin)
PCI-E4 (6+2 Pin)
SATA5 (5 Pin)
Molex2 (4 Pin)
Floppy1 (4 Pin)
ModularNon Modular
Flat CableYes
Lighting Effect30 Neon-Flex RGB
Silent ModeYes
DC to DCNo
