Technical Specifications
Picture/Display
- LCD panel type
- IPS technology
- Backlight type
- W-LED system
- Panel Size
- 23.8 inch / 60.5 cm
- Display Screen Coating
- Anti-Glare, 3H, Haze 25%
- Effective viewing area
- 527.04 (H) x 296.46 (V)
- Aspect ratio
- 16:9
- Maximum resolution
- 1920 x 1080 @ 165 Hz*
- Pixel Density
- 92.56 PPI
- Response time (typical)
- 4 ms (Gray to Gray)*
- MPRT
- 1 ms
- Low Input Lag
- Yes
- Brightness
- 250 cd/m²
- SmartContrast
- Mega Infinity DCR
- Contrast ratio (typical)
- 1100:1
- Pixel pitch
- 0.2745 x 0.2745 mm
- Viewing angle
- 178º (H) / 178º (V)
- @ C/R > 10
- Flicker-free
- Yes
- Color gamut (min.)
- DCI-P3 94.1%*
- Color gamut (typical)
- NTSC 80.5%*, sRGB 99.9%*, Adobe RGB 90.4%*
- Picture enhancement
- SmartImage game
- Display colors
- 16.7 M
- Scanning Frequency
- 30 – 200 kHz (H) / 48 – 165 Hz (V)
- LowBlue Mode
- Yes
- EasyRead
- Yes
- sRGB
- Yes
- AMD FreeSync™ technology
- Premium
Connectivity
- Signal Input
- HDMI x 2, DisplayPort x1
- HDCP
- HDCP 2.2 (HDMI / DisplayPort)
- Audio (In/Out)
- Audio out
- Sync Input
- Separate Sync
Convenience
- User convenience
- Power On/Off
- Menu/OK
- Input/Up
- Game Settings/Down
- SmartImage game/Back
- OSD Languages
- Brazil Portuguese
- Czech
- Dutch
- English
- Finnish
- French
- German
- Greek
- Hungarian
- Italian
- Japanese
- Korean
- Polish
- Portuguese
- Russian
- Spanish
- Simplified Chinese
- Swedish
- Turkish
- Traditional Chinese
- Ukrainian
- Other convenience
- Kensington lock
- VESA mount (100x100mm)
- Plug & Play Compatibility
- DDC/CI
- Mac OS X
- sRGB
- Windows 10 / 8.1 / 8 / 7
Stand
- Height adjustment
- 130 mm
- Pivot
- -/+ 90 degree
- Swivel
- -/+ 45 degree
- Tilt
- -5/20 degree
Power
- On mode
- 24 W (typ.)
- Standby mode
- 0.5 W (typ.)
- Off mode
- 0.3 W (typ.)
- Power LED indicator
- Operation – White
- Standby mode- White (blinking)
- Power supply
- External
- 100-240VAC, 50-60Hz
Dimensions
- Product with stand(max height)
- 540 x 513 x 213 mm
- Product without stand (mm)
- 540 x 321 x 43 mm
- Packaging in mm (WxHxD)
- 600 x 526 x 164 mm
Weight
- Product with stand (kg)
- 3.70 kg
- Product without stand (kg)
- 2.40 kg
- Product with packaging (kg)
- 5.65 kg
Operating conditions
- Temperature range (operation)
- 0°C to 40 °C
- Temperature range (storage)
- -20°C to 60 °C
- Relative humidity
- 20%-80 %
- Altitude
- Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
- MTBF
- 50,000 (Excluded backlight) hour(s)
Sustainability
- Environmental and energy
- RoHS
- Recyclable packaging material
- 100 %
- Specific Substances
- Mercury free
- PVC / BFR free housing
Compliance and standards
- Regulatory Approvals
- CB
- TUV/ISO9241-307
- TUV-BAUART
- CU-EAC
- EAEU RoHS
- PSB
- CE Mark
- FCC Class B
- ICES-003
Cabinet
- Color
- Black
- Finish
