SPECIFICATIONS
Radiator Size 360 mm
Radiator Dimensions (WxDxH) 394 x 119.6 x 27.2mm / 15.51 x 4.69 x
1.06 inches
Radiator Material Aluminum
Water Cooling Tube Material EPDM + IIR
Number of Fans 3
Fan Dimensions (WxDxH) 120 x 120 x 25 mm / 4.7 x 4.7 x 0.98
inches
Fan Air Flow 64.89 CFM
Fan Bearing Rifle Bearing
Fan Speed 500~2050 ± 150 RPM
Fan Life Expectancy 40,000 hrs@40℃
Fan Rated Current 0.14 A±0.028 A
Fan Power Consumption 1.68W±0.336W
PWM Mode Yes
Cable Length (PWM Cable) 600 mm; 23.62 inches
Fan Connector 5V ARGB 3-PIN Header
Block Lighting ARGB GEN2
Fan Lighting ARGB GEN2
Pump Life Expectancy 50,000 hours in typical use
Pump Noise Level 20 dBA ( Max )
Pump Rated Current 0.21A±0.042
Pump Power Consumption 2.52W±0.504W
Pump Speed 3400 RPM ± 10% RPM
Pump Connector 4-PIN Header
5V ARGB 3-PIN Header ( Female )
Cold Plate Material Copper
Block Dimensions (WxDxH) 71.23 x 69.47 x 75.05 mm
Intel Socket Support LGA 1851 / 1700
AMD Socket Support AM5 / AM4
Accessories Thermal paste x 1
Screws x 12
