Description
Product Specifications
Model No.
SST-LD05-B-ARGB (Black)
SST-LD05-W-ARGB (White)
SST-LD05-W-ARGB (White)
Material
Steel, plastic, tempered glass
Drive bay
Internal
- 3.5″ x 1 / 2.5″ x 1 / 2.5″ x 2 [1]
3.5″ x 1
2.5″ x 1
Cooling system
Rear
- 120mm x 1
(120mm x 1 ARGB fan included)
Top
- 120mm x 3 / 140mm x 2
Internal
- Motherboard Tray:120mm x 2(120mm x 2 ARGB fans included)
PSU Shroud:Top:120mm x 3
Front:80mm x 2
Radiator support
Rear
- 120mm
Top
- 120mm / 140mm / 240mm / 280mm / 360mm[2]
Internal
- Motherboard Tray:240mm[3]
Limitation of CPU cooler
173mm
Expansion slot
7
Limitation of expansion card
Length:410mm
Width:179mm
Width:179mm
Power supply
Standard PS2 (ATX)
Limitation of PSU
200mm
Front I/O port
USB Type-C x 1
USB 3.0 x 2
Audio x 1
Mic x 1
USB 3.0 x 2
Audio x 1
Mic x 1
Dimension
220mm (W), x 491.5mm (H), x 427.6mm (D), 46.24 liters
8.66″ (W), x 19.35″ (H), x 16.83″ (D), 46.24 liters
8.66″ (W), x 19.35″ (H), x 16.83″ (D), 46.24 liters
Remark
[1] When installing two 2.5″ SSDs in this position, ensure the connectors face the rear to prevent interference.
[2] When mounting a 360mm radiator in this position, ensure the inlet and outlet tubes are orientated toward the front to prevent interference.
[3] When mounting a 240mm radiator in this position, graphics card clearance is limited to 281mm, including power connectors. Ensure the fans are installed between the radiator and motherboard tray to accommodate this restriction.
[2] When mounting a 360mm radiator in this position, ensure the inlet and outlet tubes are orientated toward the front to prevent interference.
[3] When mounting a 240mm radiator in this position, graphics card clearance is limited to 281mm, including power connectors. Ensure the fans are installed between the radiator and motherboard tray to accommodate this restriction.
