Description
SPECIFICATIONS
Product Name
Alphard Pro
Dimensions
435x215x495mm (LxWxH)
Motherboard Support
E-ATX (≤ 272mm if Side Fan Installed),
ATX, M-ATX, Mini-ITX
Drive Bays
HDD Cage (Top): 2.5″& 3.5″ Combo x1
HDD Cage (Bottom): 3.5″ x1
Fan Support
Top: 120mm x3 or 140mm x2
Side: 120mm x2 (E-ATX Wide ≤ 272mm)
Rear: 120mm x1
PSU Length Limitation
220mm
CPU Cooler Clearance
165mm
Material
Steel
Expansion Slots
Standard PS2 ATX PSU
Power Supply
7 Standard Slots
I/O Panel
USB3.0 x2
HD Audio
Radiator Support
Top: 240/280/360
Side: 240 (E-ATX Wide ≤ 272mm
& GPU Length ≤ 280mm)
Rear: 120
GPU Length Limitation
280mm (With Side Fan)
410mm (Without Side Fan)
