Description
Technical specifications & manual
General Specifications
TIM
MX-6 (0.8 g)
Warranty
6 Years
Operating Ambient Temperature
0—40 °C
Pump
800–2800 rpm
(PWM controlled)
(PWM controlled)
Current | Voltage
0.35 A | 12 V DC
Cold Plate
Copper, Micro Skived Fins
Tube Length
450 mm
Tube Diameter
Outer: 12.4 mm
Inner: 6.0 mm
Inner: 6.0 mm
Weight
1675 g
Compatibillity
Intel
LGA1851, LGA1700
AMD
AM5, AM4
PI | NNPI
330 | 238
Radiator
Material
Aluminium
Dimensions
277 (L) x 120 (W) x 38 (H) mm
VRM Module
VRM Fan
400–2500 rpm
(PWM-controlled)
(PWM-controlled)
Current | Voltage
0.05 A | 12 V DC
Radiator Fan
General
2x P12 Pro
Speed
600–3000 rpm
Airflow
77 cfm | 131 m³/h3/h
Static Pressure
6.9 mmH2O
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.33 A | 12 V DC
Connector
4-Pin Fan Plug
