Description
Product Specifications
Model No.
SST-FA512Z-BG (Black, tempered glass, 3 ARGB fans, ARGB light strip)
SST-FA512Z-BG-V2 (Black, tempered glass, 4 ARGB fans, ARGB light strip)
SST-FA512Z-BG-V2 (Black, tempered glass, 4 ARGB fans, ARGB light strip)
Material
Steel, plastic, tempered glass
Motherboard
Drive bay
Internal
- 3.5″ / 2.5″ x 1
3.5″ x 1
2.5″ x 2
Cooling system
Front
- 120mm x 3 / 140mm x 2
(120mm x 3 ARGB fans included)
Rear
- 120mm x 1
SST-FA512Z-BG-V2: (120mm x 1 ARGB fan included)
Top
- 120mm x 2 / 140mm x 2
Radiator support
Front
- 120mm / 140mm / 240mm / 280mm / 360mm
Rear
- 120mm
Top
- 120mm / 140mm / 240mm / 280mm
Limitation of CPU cooler
162mm
Expansion slot
7
Limitation of expansion card
Length : 360mm
Width : 169mm
Width : 169mm
Power supply
Standard PS2 (ATX)
Limitation of PSU
190mm (Drive cage installed at the front position)
160mm (Drive cage installed at the rear position)
160mm (Drive cage installed at the rear position)
Front I/O port
USB Type-C x 1
USB 3.0 x 2
Audio x 1
Mic x 1
USB 3.0 x 2
Audio x 1
Mic x 1
Dimension
210mm (W), x 483.2mm (H), x 426.77mm (D), 43.31 liters
8.27″ (W), x 19.02″ (H), x 16.8″ (D), 43.31 liters
8.27″ (W), x 19.02″ (H), x 16.8″ (D), 43.31 liters
Net weight
SST-FA512Z-BG: 6.83 kg
SST-FA512Z-BG-V2: 6.96 kg
SST-FA512Z-BG-V2: 6.96 kg
