Description
SPECIFICATIONS
Dimensions
420x285x452mm (LxWxH)
Motherboard Support
E-ATX (≤ 272mm if Side Fan Installed)
ATX (Support Back Plug)
Micro ATX (Support Back Plug)
Mini ITX
Drive Bays
HDD Bracket:
2.5″ & 3.5″ x1 or 2.5″ x2
Fan Support
Top: 120mm x3 or 140mm x2
Side: 120mm x3 (EATX Wide ≤ 272mm) or
140mm x2 (ATX MB Only)
Bottom: 120mm x3 or 140mm x2
Rear: 120mm x1
PSU Length Limitation
220mm
CPU Cooler Clearance
175mm
Material
Steel
Power Supply
8 Standard Slots
Expansion Slots
Standard PS2
ATX PSU
I/O Panel
USB3.0 x1
USB2.0 x1
HD Audio
Radiator Support
Top: 360/280/240
Side: 360/280/240 (ATX MB Only)
GPU Length Limitation
400mm
